3.01 MW Demonstration Wind Farm
Various
Wind Energy technologies in Complex Terrain topography
Location:
Lavreotiki, SE Attica, Greece
( Photo taken from the 100m high meteo-mast,
situated NNW of the Wind Farm, before the nacelle installation of the
ÏÁ-600 )
On-Line monitoring of the Wind Farm, using a mobile phone:
Send an SMS message with the character ? to +30 6944 560 987 and you will receive instantly the last 10min statitistics of the Wind Farm operation.
Time refers to GMT+02:00 winter time (Greece)
Power (kW) variation of the Wind Farm and of each turbine, during the
last 48 hours.
Mean values of 10min data.
Contribution of each turbine to the Wind farm energy production.
Inner
doughnut: last 48 hours, Outter doughnut: This
month
Mean & Max wind speed per
direction (based on the
Å40)
Normalised power vs Nacelle position
Wind Speed variation during the last 48 hours (Nacelle
anemometers)
Nacelle positions during the last 48 hours
Notice:
1) The nacelle orienation of both Vestas V47-660 and NEG-Micon is not correct due to sensor failure.
2) For various reasons (beyond CRES responsibility) both OA-500 and OA-600 are not operating anymore. "Repowering" is under consideration.
3) The energy production of the wind turbines should not be directly compared, due to the complex terrain topography, leading to different wind speeds at each turbine. The camparison can be done only after a "site calibration" procedure.
4) The produced power of the Wind Farm is measured at the MV grid (20kV). However, the power of each wind turbine is measured at the LV side (400-690V) and does not include each transformer's losses.
